DZOFilm Linglung DZO 10-24mm 20-70mm T2.9 MFT Parfocal Cine Lens for Micro Four Thirds Camera Lens Maintains Focus
Couldn't load pickup availability
10-24mm
About this item
-
20-70mm T2.9-T22 constant aperture
-
100 Degree Zoom rotation angle
-
70 Degree Iris rotation angle
-
Fast back flange adjusting mechanics: 0.3mm Fine adjustment on back flange
-
Only 157.6mm lobster length
-
DZOFILM Linglung 10-24mm T2.9 MFT Parfocal Cinema Style Zoom Lens - Front Lens Cap - Rear Lens Cap - DZOFILM 1 Year Limited Warranty
-
Compatibility: BMPCC 4k, Z Cam E2, Panasonic GH5 GH5s Camera
-
Focal Length: 10 to 24mm
-
Lens Mount: Micro Four Thirds
-
Format: MFT
DZOFilm DZO 20-70mm T2.9 MFT Parfocal Cine LensSpecs
|
Focal Length |
20 to 70mm |
|
Lens Mount |
Micro Four Thirds |
|
Lens Format Coverage |
MFT |
|
Image Circle |
21.6 mm |
|
Maximum Aperture |
T2.9 |
|
Minimum Aperture |
T22 |
|
Diagonal Angle of View |
MFT: 57.6 to 17.9° |
|
Horizontal Angle of View |
MFT: 47.5 to 14.3° |
|
Minimum Focus Distance |
From : 31.1'' / 79 cm |
|
Diaphragm Blades |
12 |
|
Gear MOD & Pitch |
Focus: 0.8 MOD / 32 Pitch |
|
Front Diameter |
80 mm |
|
Filter Thread |
77 mm |
|
Focus Scales |
Imperial |
|
Focus Rotation |
270° |
|
Iris Rotation |
70° |
|
Zoom Rotation |
100° |
|
Zoom Ratio |
3.5x |
|
Image Stabilization |
No |
|
Length |
6.2'' / 157.5 mm |
|
Weight |
2.43 lb / 1.1 kg |
DZOFilm DZO 10-24mm T2.9 MFT Parfocal Cine LensSpecs
|
Focal Length |
10 to 24mm |
|
Lens Mount |
Micro Four Thirds |
|
Lens Format Coverage |
MFT |
|
Image Circle |
21.6 mm |
|
Maximum Aperture |
T2.9 |
|
Minimum Aperture |
T22 |
|
Diagonal Angle of View |
MFT: 92.5 to 49.3° |
|
Horizontal Angle of View |
MFT: 79.7 to 40.3° |
|
Minimum Focus Distance |
From : 19.7'' / 50 cm |
|
Diaphragm Blades |
12 |
|
Gear MOD & Pitch |
Focus: 0.8 MOD / 32 Pitch |
|
Front Diameter |
80 mm |
|
Filter Thread |
77 mm |
|
Focus Scales |
Imperial |
|
Focus Rotation |
270° |
|
Iris Rotation |
70° |
|
Zoom Rotation |
100° |
|
Zoom Ratio |
2.4x |
|
Image Stabilization |
No |
|
Length |
6.11'' / 155.1 mm |
|
Weight |
2.43 lb / 1.1 kg |
